Product Highlights
Product Range
R32 Inverter Single Split
Capacities
2.0 - 6.0hp
Refrigerant
R32
SCAN THIS QR WITH YOUR PHONE TO
VIEW THE PRODUCT IN YOUR SPACE.
Wide Angle Airflow
An Auto Swing airflow-up and down automatically cools down the room thoroughly. It can adjust the airflow right and left manually to give straight or wide angle airflow distribution.
Suitable for High Ceiling
Suitable for high ceiling application as it has strong air power and can be installed up to 4.3 meter ceiling height. (model 34,100 - 47,800 Btu/h)
Fits Snugly in Tight Spaces
This unit has a slim body and able to fit more snugly in tight spaces as it requires only 30mm gap from the edge of the wall which provides great flexbility in term of installation.
Auto Restart
If there is a power outage while the equipment is operating, operations will restart in the same mode as before the power cut when electricity is restored.
Easy Clean
Non-flocking flap in which condensation does not form easily and dirt does not cling. Additionally, this unit has flat surfaces where it is easy to wipe dirt off the flat side and lower surfaces of the unit.
Tech specs
Specifications
| FHFC-A Series | ||||||||
|---|---|---|---|---|---|---|---|---|
| Indoor | FHFC50AV1 | FHFC60AV1 | FHFC71AV1 | FHFC85AV1 | FHFC100AV1 | FHFC125AV1 | FHFC140AV1 | |
| Outdoor | RZFC50BGVMM | RZFC60BGVMM | RZFC71BGVMM | RZFC85BVMM | RZFC100AVMM | RZFC125AY1M | RZFC140BY1M | |
| Type | Inverter | |||||||
| Refrigerant | R32 | |||||||
| Specifications / Model name | ||||||||
| Rated Cooling Capacity (Min-Max) | Btu/hr | 17,100 (7,800 - 19,100) | 20,500 (8,900-21,500) | 24,200 (10,900 - 27,300) | 29,000 (14,300 - 34,100) | 34,100 (17,100 - 38,200) | 42,700 (19,500 - 47,800) | 47,800 (21,200 - 52,900) |
| Rated Running Current | A | 7.33 | 8.76 | 11.00 | 13.30 | 15.90 | 6.25 | 11.00 |
| Rated Power Consumption | (W) | 1,670 | 2,000 | 2,500 | 2,990 | 3520 | 4880 | 6070 |
| COP | (W/W) | 3.00 | 3.00 | 2.84 | 2.84 | 2.84 | 2.56 | 2.31 |
| CSPF | (Wh/Wh) | 4.30 | 4.30 | 4.09 | 4.09 | 4.09 | 3.82 | 3.71 |
| Power Supply | (V/Ph/Hz) | 220-240/1/50 | 380-415/3/50 | 380-415/3/50 | ||||
| Air Flow Rate (H/M/L) | CFM | 459/-/353 | 600/-/494 | 847/-/706 | 1059/-/883 | 988/847/706 | 1094/953/812 | 1200/1024/847 |
| Sound Pressure Level - Indoor (H/M/L) | (dBA) | 38/-/33 | 39/-/35 | 42/-/37 | 44/-/39 | 42/38/34 | 44/41/37 | 46/42/38 |
| Dimension - Indoor (H x W x D) | mm | 195 X 960 X 680 | 195 X 1,160 X 680 | 195 X 1,400 X 680 | 195 X 1,590 X 680 | 235 X 1,590 X 690 | 235 X 1,590 X 690 | 235 X 1,590 X 690 |
| Dimension - Outdoor (H x W x D) | mm | 615 X 845 X 300 | 615 X 845 X 300 | 615 X 845 X 300 | 695 X 930 X 350 | 695 X 930 X 350 | 990 X 940 X 320 | 990 X 940 X 320 |
| Unit weight - Indoor | (kg) | 25 | 27 | 32 | 35 | 38 | 38 | 38 |
| Unit weight - Outdoor | (kg) | 37 | 37 | 37 | 40 | 40 | 62 | 62 |
| Copper Pipe Size - Liquid | (mm) | 6.35 | 6.35 | 9.52 | 9.52 | 9.52 | 9.52 | 9.52 |
| Copper Pipe Size - Gas | (mm) | 12.7 | 12.7 | 15.88 | 15.88 | 15.88 | 15.88 | 15.88 |
| Maximum Piping Length | m | 30 | 30 | 30 | 50 | 50 | 50 | 50 |
| Maximum Piping Elevation | m | 15 | 15 | 15 | 30 | 30 | 30 | 30 |
| Controller | Wired/Wireless | |||||||
| Retail Sales Price | RM4210.00 | RM4460.00 | RM4780.00 | RM5600.00 | RM7250.00 | RM7540.00 | RM8280.00 | |
